China UL1330/1331 Fluoroplastic Insulated Wires for Electric Appliances

Product Description

UL1330/1331 Fluoroplastic Insulated Wires
Rated voltage: 600V
Testing voltage: 2500V
Temperature range:
-100~+200deg. C (1330)
-100~+150deg. C (1331)
O. D. Tolerance: +/-0.1mm
Conductor: Tinned copper
Insulator: FEP
Color: White, blue, red, black, brown, yellow, green, transparent, yellow/green.
Use: Lead wires for home electric appliances, lightings, electronic equipment and sensors etc.

Conductor			Insulation		Electrical characteristic
Spec AWG	Conductor construction No./ φmm	Diameter (mm)	Insulation thickness (mm)	Over outer diameter (mm)	Resistance 20ºC /km	Permissible ampactity 20ºC-AMR
30	1×0.25	0.25	0.20	0.65	376.13	1.27
28	1×0.31	0.31	0.25	0.81	227.39	2.02
26	7×0.15	0.46	0.46	1.38	148.94	3.22
26	19×0.10	0.50	0.46	1.42	148.94	3.22
24	7×0.20	0.61	0.46	1.53	93.25	5.15
24	19×0.12	0.60	0.46	1.52	93.25	5.15
22	7×0.25	0.76	0.46	1.68	55.00	8.73
22	19×0.15	0.76	0.46	1.68	55.00	8.73
20	7×0.31	0.95	0.46	1.87	34.60	13.87
20	19×0.19	0.96	0.46	1.88	34.60	13.87
18	7×0.39	1.19	0.46	2.11	21.80	22.02
18	19×0.235	1.18	0.46	2.10	21.80	22.02
16	7×0.50	1.53	0.46	2.45	13.70	35.04
16	19×0.30	1.51	0.46	2.43	13.70	35.04
14	19×0.37	1.86	0.50	2.86	8.62	55.68
12	19×0.46	2.32	0.50	3.32	5.43	88.40
10	37×0.43	3.02	0.50	4.02	3.41	140.76
