UL 1331 Standard RoHS Compliance 200c 600V Fluoroplastic FEP Wire Cables

Product Description

UL 10126 Standard RoHS Compliance 150C 200C 600V fluoroplastic ETFE wire cable

Charcteristic:
High temperature resistance,low temperature resistance anti-acid,anti-oil,antisepsis and moisture,UL758&UL1581,ROHS compliance,passed VW-1.

Application:
Apply to various household appliances,Lighting illumination & lighting,electrical equipments,temperature sensors

Conductor			Insulation		Electrical Characteristic		packing
AWG	Conductor construction NO×Φmm	Diameter mm	Insulation Thickness mm	Over Diameter mm	Realst.max Cuc.c 20ºC ohm/km	Permissiblle ampacity 20ºC-AMR	mt/coils
30	1×0.254	0.25	0.15	0.55	376.96	1.27	610
28	1×0.32	0.32	0.18	0.67	237.25	2.02	610
26	7×0.16	0.48	0.23	0.92	148.94	3.22	305
26	19×0.10	0.50	0.23	0.96	148.94	3.22	305
24	7×0.203	0.61	0.23	1.07	93.25	5.15	305
24	19×0.12	0.60	0.23	1.06	93.25	5.15	305
22	7×0.254	0.76	0.23	1.22	55.00	8.73	305
22	19×0.16	0.80	0.23	1.26	55.00	8.73	305
20	7×0.32	0.94	0.23	1.40	34.60	13.87	305
20	19×0.19	0.96	0.23	1.42	34.60	13.87	305
18	7×0.39	1.17	0.23	1.63	21.80	22.02	305
18	19×0.235	1.18	0.23	1.64	21.80	22.02	305
16	7×0.50	1.50	0.23	1.96	13.50	35.04	305
16	19×0.30	1.51	0.23	1.97	13.50	35.04	305
14	19×0.37	1.86	0.30	2.46	8.62	55.68	305
12	19×0.47	2.35	0.30	2.95	5.43	88.40	305
10	37×0.43	3.1	0.30	3.70	3.41	140.76	305

Our products can meet UL, VDE, CCC, PSE ,CE certificate requirement and the products are accord with ROHS and REACH Halogen free standard.
Our factory could meet ISO9001:2008 management systems standard. There are 10 production lines in high quality, precise, automation which supporting daily capacity 300,000km cables at least.

Q1: Can I get a free sample?
A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.

Q2: How could I pay?
A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.

Q3: What is your packing way? Can I have the customized package?
A3: We have the standard export package. For more details about the customized package, please contact us.

Q4: What is the delivery lead time?
A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.

Q5: Are you a factory or a trading company?
A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.

Q6: Where is your main market?
A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.

Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional service

Why choose us
1. Production
    Qualified production, competitive price, professional service.
2. Technology
    Professional R& D team
3. Equipment
    With completive testing equipment.
4. Quality
    UL/ CE/ FCC/ RoHS/ Reach certificate
