China Guangtai Single Channel Gain Block Booster Mini EDFA Amplifier Module Sba4100-GM01

Product Description

SBA4100-GM01 is a single-channel gain block booster EDFA module, adopts subminiature 40×70×12mm compact package. The module uses high performance non-cooling pump laser, combined with artistic package and best optic performance, creating the best flexible and variable low-cost amplifier in the market. This module is suitable for multiple network application, especially the application that requires 40GB/S transmission speed.
SBA4100-GM01 gain block booster EDFA module adopts the standard version of single channel and narrow bandwidth. A standard 6-Pin ( optional 14-PIN ) electric connector allows the simple electric connection.
SBA4100-GM01 gain block booster EDFA module, main installed behind the optical transmitter to increase the output power of the transmitter and extend the signal transmission distance.

1. Gain block
2. Wide operating temperature range
3. Output power 13~19dBm optional
4. Small form factor package (40×70×12mm)
5. Low power consumption
6. Low cost

1. Metropolitan and access networks
2. CATV
3. Single-channel or DWDM sub-systems
4. Optical Add/Drop and Cross-Connects
5. Transmitter and Receiver Amplification
6. Power equalization and flexible pre-emphasis

Performance				Min.	Typ.	Max.
Optical properties	Operating wavelength range		(nm)	1528		1564
	Input optical power (pin)		(dBm)	-10		+4
	Total output power @ Pin=0dBm	SBA4113-GM01	(dBm)	13
		SBA4114-GM01		14
		SBA4115-GM01		15
		SBA4116-GM01		16
		SBA4117-GM01		17
		SBA4118-GM01		18
		SBA4119-GM01		19
	Noise figure		(dB)		4.0	5.0
	Polarization dependent gain (PDG)		(dB)			0.3
	Polarization mode dispersion (PMD)		(dB)			0.3
	Polarization dependent loss (PDL)		(ps)			0.3
	Pump power leakage		(dB)			-30
	Output & input isolation		(dB)	30
	Return loss		(dB)	45
	Return loss		(dB)	55
General feature	Pump laser threshold current (70ºC)		(mA)		50	70
	Pump laser operating current (BOL)		(mA)			600*
	Pump laser operating voltage		(V)		1.75	2.2
	Output monitor PD responsivity (70ºC)		(μA/mW)	1.0		25
	Output monitor PD reverse voltage		(V)		5	20
	Output monitor PD forward current		(mA)			10
	Dark current (-5V, 25ºC)		(nA)			5
	Fiber type			SMF-28, 900μm loose tube
	Connector type			LC, SC, FC
	Connector polish			UPC,APC
	Operating temp.		(ºC)	-5		70
	Storage temp.		(ºC)	-40		+85
	Relatice humidity		(%RH)	+5		+95
	Size (W)×(L×(H)		( mm )	40×70×12

* 70ºC, 18dBm output.

Guangtai Single Channel Gain Block Booster Mini EDFA Amplifier Module Sba4100-GM01

1. What are the payment terms of payment?
Usually, we accept T/T, PayPal, Western Union, and Alibaba Trade Assurance. You can select the terms of payment which is more convenient for you.

2. What about the lead time?
Usually, if there's stock, we ship the goods within 5-7 working days after the deposit is confirmed. If it is out of stock, the lead time depends.

3. How about the shipping?
When the package is small, we will deliver the goods via international Express like FedEx , DHL,TNT and UPS and so on. Door to door delivery service will be provided; while the goods have high weight and volume, we suggest using air or sea shipment.

4. Can you do OEM for us?
Yes. if there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.

5. What are the advantages of your products?
A. Good quality and competitive prices
B. Strict quality control during production process.
C. Professional operations in processes of production, sales, assembling, packaging and shipping
D. Good after-sale service. Professional online technical support can be provided. Moreover, if there is any problem of the goods, we will help to solve the problem or provide replacement of the goods

6. How about the Warranty?
There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands.
