Guangtai C-Band DWDM Line EDFA Module 125X150X20mm Wla4200-FM05
Product DescriptionWLA4200-FM05 series is a gain flatness line EDFA Module which is specifically designed for C-Band 44 channels optic transmission system. It adopts the most excellent optical performance, the most advanced electronic control technology and the most complete software functionalities......
Send Inquiry
Product Description
WLA4200-FM05 series is a gain flatness line EDFA Module which is specifically designed for C-Band 44 channels optic transmission system. It adopts the most excellent optical performance, the most advanced electronic control technology and the most complete software functionalities; it is featured with wide working wavelength range, low noise and excellent gain flatness. WLA4200-FM05 is mainly installed in middle of transmission line, replacing the traditional relay, to compensate the optical power loss in the line and extend the optical signal transmission distance
WLA4200-FM05 adopts the world's top class pump laser; advanced electronic circuit and low consumption design, greatly reduced the heat power consumption of complete equipment. Perfect APC, ACC and ATC control, ensures the long life and high reliability work of pump laser. RS232 offer serial communication. The laser will switch off automatically if optical power is missing, which offers security protection for the laser.
WLA4200-FM05 adopts 125×150×20mm chassis size; signal unit +5VDC power supply.
1. Wide working wavelength: 1529.16~1563.86nm
2. Accord with the communication technology requirements of 44 channels DWDM system
3. Excellent gain flatness feature (GF<1.0dB)
4. Low noise figure
5. Standard RS232 communication interface.
6. Low power consumption.
7. Excellent P/P ratio in area.
1. 44 channels DWDM system
2. Long distance trunk network
3. MAN or access network
4. All kinds of SDH/PDH transmission system
5. FTTx PON
| Performace | Index | Supplement | ||||
| Min. | Typ. | Max. | ||||
| Optical feature | Working wavelength range (λ) | (nm) | 1529.16 | 1563.86 | ITU 88CH | |
| No. of working channel | (CH) | 1 | 44 | |||
| Input Optical Power (Pi) | (dBm) | -25 | -10 | |||
| Saturation output power(Po) | (dBm) | 13 | 23 | |||
| Gain flatness | (dB) | 0.7 | 1.0 | Value of Peak to Peak | ||
| Noise figure | (dB) | 5.0 | Max ouput , Max. gain | |||
| Polarization dependence loss (PDL) | (dB) | 0.3 | ||||
| Polarization dependence Gain (PDG) | (dB) | 0.3 | ||||
| Polarization mode dispersion (PMD) | (ps) | 0.3 | ||||
| Pump leakage power | (dB) | -30 | ||||
| Input/Output optic isolatioin | (dB) | 30 | ||||
| Echo loss | (dB) | 45 | UPC | |||
| 55 | APC | |||||
| Optical Supervisory Channel Wavelength | (nm) | 1500 | 1510 | 1520 | ||
| Transient feature | Transient setting time (16 dB Add / Drop) | (μs) | 700 | |||
| Transient Overshoot (16 dB Add / Drop) | (dB) | -1.5 | +1.5 | |||
| Transient gain changes | (dB) | -0.5 | +0.5 | |||
| General feature | Communication interface | RS232 | ||||
| Fiber type | Coming SMF-28TM or equivalent | |||||
| Pigtail buffer diameter | (μm) | 900 | ||||
| Pigtail length | (mm) | 1000 | ||||
| Power supply | (V) | +4.75 | +5.0 | +5.25 | ||
| Power consumption | (W) | 2.0 | 1.0 | |||
| Working temp. | (ºC) | -5 | +70 | |||
| Storage temp. | (ºC) | -40 | +85 | |||
| Working relative humidity | (%) | 5 | +95 | |||
| Size (W)×(D)×(H) | (mm) | 125×150×20 | ||||
