Best Price 32 Outputs EDFA 1550nm Optical Amplifier with Wdm
Description 32Way Output EDFA 1550nm Optical Fiber Amplifier With WDM,Output ports number:32Way,Output power per port:18,19,20... dBm is optional,CATV pass through wavelength:1545~1565nm,PON pass through wavelength:1260~1360 ,1480~1500,Power supply voltage:AC160V - 250V(50 Hz); or DC48V,Dimension:48......
Send Inquiry
Product Description
★Description
32Way Output EDFA 1550nm Optical Fiber Amplifier With WDM,Output ports number:32Way,Output power per port:18,19,20... dBm is optional,CATV pass through wavelength:1545~1565nm,
PON pass through wavelength:1260~1360 ,1480~1500,Power supply voltage:AC160V - 250V(50 Hz); or DC48V,Dimension:483mm(L)× 440mm(W)× 88mm(H).American standard plug or European standard plugs is optional.
★Application
* FTTH network
* CATV network
* Single-mode fiber 1550 amplification network
★Product Performance
Item | Unit | Technique parameters | ||
CATV pass through wavelength | nm | 1545 - 1565 | ||
PON pass through wavelength | nm | 1260 - 1360 ,1480 - 1500 | ||
PON insertion loss | dB | <0.8 | ||
Isolation | db | >15 | ||
CATV optical input power range | dBm | -3 - +10 | ||
Maximum optical output power | dBm | 36 | ||
Output power stability | dBm | ±0.5 | ||
Noise figure | dB | ≤ 5.0 (Optical input power 0dBm, λ=1550nm) | ||
Return loss | Input | dB | ≥ 45 | |
Output | dB | ≥ 45 | ||
Optical Connector Type |
| SC/APC | ||
C/N | dB | ≥ 50 | Test condition according to GT/T 184-2002. | |
C/CTB | dB | ≥ 63 | ||
C/CSO | dB | ≥ 63 | ||
Power supply voltage | V | A: AC160V - 250V(50 Hz); B: DC48V | ||
Consumption | W | ≤ 70 | ||
Operating temperature range | °C | -10 - +42 | ||
Maximum operating relative humidity | % | Max 95% no condensation | ||
Storage temperature range | °C | -30 - +70 | ||
Maximum storage relative humidity | % | Max 95% no condensation | ||
Dimension | mm | 483(L)× 440(W)× 88(H) | ||
★Specifications
Item | Unit | Parameter | ||
Working wavelength | nm | 1535~1565 | ||
Input optic power | dBm | -5~+10 | ||
Total output power | dBm | 28~33 | 34~37 | 38~40 |
Noise figure | dB | ≤5.0 | ≤5.5 | ≤6.0 |
output port number |
| 4,8,16,32,64 | ||
Each port output power | dBm | 10~23 | ||
Output power adjustable range | dB | -4.0 to +0.2 | ||
Output power stability | dB | ≤±0.2 | ||
Return loss | dB | ≥45 | ||
Pump leakage power | dBm | ≤-30 | ||
Polarization relevant gain | dB | ≤0.3 | ||
Polarization membrane dispersion | Ps/nm | ≤0.5 | ||
Optic Connector |
| SC/APC,FC/APC or LC/APC | ||
Power Supply Voltage | V | AC110~265(50~60Hz)or DC48V | ||
Power Consumption | W | ≤55 | ≤75 | ≤120 |
Working Temperature | ºC | -5~+50 | ||
Max. Working Relevant Humidity | % | Max. 85%, no condensation | ||
Storage Temperature | ºC | -40~+80 | ||
Outer size | mm | 483×440×88 | ||
Packing size | mm | 550×540×180 | ||
Net weight | Kg | 8.45 | ||
Total weight | Kg | 9.50 | ||
