Full Function Single Channel Small Form Factor Booster EDFA Module Amplifier Module (HNSA-F4000 Series)
HNSA-F4000 seriesFull Function Single Channel Small Form Factor Booster EDFA Module Amplifier Module Product descriptionHNSA-F4100 is a full-function single channel booster EDFA module (Amplifier Module) with digital control electronics, adopts subminiature 40×70×12mm compact pac......
Send Inquiry
Product Description
HNSA-F4000 series
Full Function Single Channel Small Form Factor Booster EDFA Module Amplifier Module
Product description
HNSA-F4100 is a full-function single channel booster EDFA module (Amplifier Module) with digital control electronics, adopts subminiature 40×70×12mm compact package.The module uses high performance non-cooling pump laser, combined with artistic package and best optic performance, creating the best flexible and variable low-cost amplifier in the market.This module is suitable for multiple network application, especially the application that requires 40GB/S transmission speed.
HNSA-F4300 is a full-function single channel Pre-Amplifier EDFA module (Amplifier Module) with digital control electronics, adopts subminiature 40×70×12mm compact package, combined with artistic package and best optic performance, creating the best flexible and variable low-cost amplifier in the market.This module is suitable for multiple network application, especially the application that requires 40GB/S transmission speed.
Product feature
- With Digital Control Electronics ( Full Functiion )
- APC,ACC mode
- RS-232 standard communication interface, (Optional I2C )
- Small form factor package (40×70×12mm)
- Low power consumption
- Low cost
- Wide operating temperature range
Main application
- Metropolitan and access networks
- CATV
- Single-channel or DWDM sub-systems
- Optical Add/Drop and Cross-Connects
- Transmitter and Receiver Amplification
- Power equalization and flexible pre-emphasis
| Performance | Min. | Typ. | Max. | ||
| Optical properties | Operating wavelength range | (nm) | 1528 | 1564 | |
| Input optical power (pin) | (dBm) | -10 | +3 | ||
| Noise figure | (dB) | 4.0 | 5.0 | ||
| Polarization dependent gain (PDG) | (dB) | 0.3 | |||
| Polarization mode dispersion (PMD) | (dB) | 0.3 | |||
| Polarization dependent loss (PDL) | (ps) | 0.3 | |||
| Pump power leakage | (dB) | -30 | |||
| Output & input isolation | (dB) | 30 | |||
| Return loss | (dB) | 45 | UPC | ||
| 55 | APC | ||||
| Fiber type | SMF-28, 900μm loose tube | ||||
| Connector type | LC, SC, FC | ||||
| Connector polish | UPC,APC | ||||
| General feature | Communication interface | RS232 | |||
| Power Supply Voltage | (V) | 3.1 | 3.3 | 3.5 | |
| Power Consumption | (w) | 1.0 | |||
| Operating temp. | (º C ) | -5 | 70 | ||
| Storage temp. | (º C ) | -40 | +85 | ||
| Operating humidity | (%RH) | +5 | +95 | ||
| Size (W)×(L×(H) | ( mm ) | 40×70×12 | |||
